HIGH STRENGTH BRASS
HIGH STRENGTH BRASS
It is a material resistant to very high static loads at slow speed.
It is recommended for:
- Aerospace
- Heavy industry
- Public works
- The steel industry
- The shipbuilding industry
- The mechanical and chemical industry
- TP machines
- The paper industry
- Sugar factory…
It can be used for slides, pressure nuts, grains,…
| ZN | AL | FE | MN | RM MPA | RP 0.2 MPA | A5 % | HB | ||
|---|---|---|---|---|---|---|---|---|---|
| CUZN19AL6 | 23.5 | 6 | 2.5 | 3.5 | 750 | 500 | 8 | >220 | |
| CUZN23AL4 | 25 | 4.8 | 2.5 | 3.8 | 550 | 250 | 12 | >150 | |
| CUZN25AL5 | 24 | 4.1 | 2.5 | 3.5 | 750 | 480 | 6 | >190 | |
| CUZN34AL2 | 34 | 1.75 | 1.8 | 2.75 | 600 | 260 | 12 | >150 | |
| CUZN37AL1 | 37 | 1 | 450 | 170 | 25 | >110 |
“Our products are compatible with the following standards: EN1982, Din1714, UNI, ASTM B505, GAM-MM12”
The values shown are averages. Although this information has been verified, our responsibility cannot be engaged.
